首页 > 供应产品 > 三角包茶叶袋泡茶包装机电子秤,自动计量
三角包茶叶袋泡茶包装机电子秤,自动计量
浏览: 785
品牌: 三角包
单价: 228000.00元/台
最小起订量: 1 台
供货总量: 120 台
发货期限: 自买家付款之日起 15 天内发货
有效期至: 长期有效
最后更新: 2021-06-13 21:58

详细信息

    QD-20

全自动三角包袋泡茶包装机器

尼龙三角茶包采用进口日本的环保尼龙、无纺布材质,是经过国家安全检验的无毒、无细菌、耐热的高质感食品级滤材,包装上手拉纸片的单色印刷面,也是日本进口无毒食用印墨制成,并能够可降解,减少环境污染问题。它的封口采用了的方法-----超声波无痕封口,紧密、卫生、安全,减少了多余的封边宽度,完全不浪费一丝滤材,较于普通袋泡茶,此种塑造高品质感袋泡茶形象,带来美观和感,更容易让大众接受。

与普通滤纸包装的袋泡茶相比,这种茶包在热水注入后,能够以最快的时间使茶叶伸展开来并保有素材原味、清香自然,而且不损伤茶袋,可多次冲泡、久泡,突出了包材的坚韧与不易撕破,透明网状的设计使茶叶的风味更加地发挥出来,让消费者可以观外形、闻香气、看汤色、尝茶味、察叶底,原片原味犹如现泡,让品茗不再局限于容器,让您随时随地均可享受更便利的现代生活!

主要特点:

1.通过超声封口切断方式,使抽出性突出且外观形状漂亮的茶包的生产成为可能

2.包装能力达2000-2400袋/小时。

3.用带标签的包装材料可以简单生产出带标签的茶包。

4.滑动容积计量方式可以很容易在变换填充物。

5、根据客户茶叶的形状可选电子秤计量。

6、气动原件用日本MSC、电器原件用德国施耐德。

7、采用日本三菱的PLC控制器。触膜屏操作、使性能更稳定,操作更简单,更具人性化。

1

生产速度

35~40袋/ 分

2

茶叶含量

≤3±0.5 g / 袋

3

茶叶要求

茶叶长度≤15㎜,呈扁平状,否则秤量精度会下降。

4

袋纸要求

用户自配日本进口的附带标签线的尼龙布或无纺布(见照片样品)

5

放卷数量

1个

6

放卷纸芯内径

Φ76㎜

7

放卷外径

≤Φ400㎜

8

封切形式

采用世界工艺电脉冲封切法

9

封切装置数量

2套

10

电器配置标准

气动元件、按钮、交流接触器

都采用外资企业或中外合资企业产品。

11

气源压力

≥0.6Mpa(由定做方保证供气)

12

机内电机用电功率

约 1.1 Kw(380V)(以设计为准)

13

操作人员

1人

14

设备外形

约 L 800×W 700×H 2000(㎜)(以设计为准)

15

设备重量

约800㎏(以设计为准)

全自动三角包袋泡茶包装机器



Nylon triangle tea bag adopts the imported environmental nylon, weaving cloth material from Japan, which is of sense of high quality food class filter material without poison and bacteria, with heat-resistance approved by China safety inspection, the single color printing of pulling paper on packing is made from imported poisonless ink from Japan suitable for food, and couldrecyclr and reduce the environmental pollution. Of which the sealing take use of unique method-ultrasonic mark sealing, tight, sanitary, safety, reducing abundant sealing width, without wasting filter material, this plastic high quality sense of tea bag image is more natural and delicated fragrance compared with common tea bag, which is more beautiful and high level, and it is more easy for public to accept.

Comparing with common tea bag, this tea bag could extend itself quickly after immerse in hot water, preserving the original taste, delicate fragrance and natural, do not hurt tea bag, could immerse for many times, featuring the stout of material and it is not easy to tear off, the design of transparent net makes the taste of tea plays more completely, the consumer could see the appearance, smell the fragrance, look the color, taste and check tea with original taste just like the fresh tea, let the taste not restricted in container, you could enjoy more convenient modern life at any time and place. The choice of volume measurement, and electronic scales measuring.

Produce speed

35-40bags/min

Tea content

≤3±0.5 g/bag

Tea request

Tea length≤15㎜,assumes the platy, otherwise the weighing precision will drop.

Bag paper request

Label line nylon or adhesive-bonded cloth(picture sample will be enclosed)

Roll quantity

1

Rolled paper core inside diameter

Φ76㎜

Rolled outer diameter

≤Φ400㎜

Seal cutting

World newest craft electricity pulse to seal cuts

Seal cutting equipment

2 sets

Standard electric appliance configure

Pneumatic element,button,exchange contact device

Source pressure

≥0.6Mpa

Motor power

Approximately 1.1kw(380v)

Operate person

1

Machine size

L800*W700*H2000(mm)

Machine weight

800kg
